M-12
| 格表 / Specifications M-12 目錄下載 | ||
|
頻率響應 |
Frequency Response |
55Hz-18KHz(±3dB) |
|
單元組成 |
Drivers |
1×12”(300mm)/3” voice coil LF |
|
1×1.4(36mm)/3” voice coil HF |
||
|
額定功率 |
Rated Power |
300W r.m.s ,1200W peak |
|
靈敏度 |
Sensitivity |
98dB/1m/1w |
|
最大聲壓級 |
Maximum SPL |
124dB comtinuous,130dB peak |
|
額定阻抗 |
Impedance |
8Ω |
|
擴散角度 |
Dispersion |
90∘ |
|
分頻點 |
Crossover Frequency |
1.5KHz |
|
輸入方式 |
Connectors |
2×NL4/1+1- |
|
吊裝附件 |
Fittings |
1×Top hat fitting |
|
尺寸W×H×D(mm) |
Dimensions |
寬540×高360×深426 |
| 重 量 | Weight | 16.9kg |
